Product Description

• Engine
• Engine TypeSingle cylinder, 2-stroke
• Displacement293.2 cc
• Cooling SystemLiquid Cooling
• Bore72 mm
• Stroke72 mm
• StarterElectric starter
• Fuel SystemTPI, Dellorto throttle body Ø 39mm
• Engine ManagementContinental EMS
• Battery
• BatteryLithium Ion 12.8V 2Ah
• Drivetrain
• Transmission6 gears
• Final Drive13:51
• ClutchWet multi-disc DDS-clutch, Magura hydraulics
• Chassis
• Frame TypeCentral double-cradle-type 25CrMo4 steel | Subframe: Carbon fiber reinforced polyamide
• Suspension
• Front SuspensionWP XACT-USD, Ø 48 mm
• Rear SuspensionWP XACT Monoshock with linkage
• Front Travel (in./cm.)310 mm
• Rear Travel (in./cm.)300 mm
• Brakes
• Front braking systemDisc brake Ø 260 mm Magura
• Rear braking systemDisc brake Ø 220 mm Magura
• Wheels & Tires
• Front Tire90/90-21"
• Rear Tire110/100-18"
• Dimensions
• DimensionsTriple Clamp Offset: 22 mm
• Chain Type5/8 x 1/4"
• SteeringHead Angle: 26.1°
• Ground Clearance370 mm / 14.8 in
• Seat Height950 mm / 37.4 in
• Wheelbase1,485 ± 10 mm / 58.5 ± 0.4 in
• Capacities
• Fuel CapacityTank, approx: 8.5 l / 2.25 gal
• Weights
• WeightWithout fuel, approx: 101.5 kg / 223.8 lbs
